Custom Heated Cooled Pellet Die
Product Description
Heated Cooled Pellet Die Custom Diameter Sizes: >5mm up to 16mm (specify diameter)
Includes (4) hardened 440C stainless steel anvils.
Precision manufactured from hardened 440C stainless steel. The assembly includes a black anodized heating/cooling jacket, die chamber, a removable base with a vacuum attachment, (4) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.
Attaching 1/4" tubing from a heated/cooled circulating bath to the die jacket's inlet/outlet ports provides for integrated liquid heating and cooling capability at temperatures between -4 to +212 degrees F (-20 to +100 degrees C).
Optional: Tungsten Carbide Anvils
Includes (4) hardened 440C stainless steel anvils.
Precision manufactured from hardened 440C stainless steel. The assembly includes a black anodized heating/cooling jacket, die chamber, a removable base with a vacuum attachment, (4) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.
Attaching 1/4" tubing from a heated/cooled circulating bath to the die jacket's inlet/outlet ports provides for integrated liquid heating and cooling capability at temperatures between -4 to +212 degrees F (-20 to +100 degrees C).
Optional: Tungsten Carbide Anvils
